Nā palena huahana
|
PARAMETER |
CO32P6 |
OLELO HOOLAHA |
|
Laulā alapine ʻino |
10 ~ 800MHz |
Fund.,Overtone a i ʻole PLL |
|
Volta hoʻolako |
2.5VDC/ 3.3VDC |
Hiki ke koho ʻē aʻe |
|
Hāʻawi i kēia manawa |
100mA |
Kiʻekiʻe, ke ʻano kālā haʻahaʻa Icc |
|
Paʻa pinepine |
±25ppm / ±50ppm / ±100ppm |
E nānā i ka leka ma lalo. |
|
Laulā wela hana |
−10 a i +70 degere a i ʻole −40 a 85 degere |
Loaʻa nā koho ʻē aʻe. |
|
Ka nalu puka a me ka ukana |
LVPECL / 50Ω |
I loko o Vcc−2 |
|
Kiʻekiʻe puʻemaka puka HIGH |
Vcc−1.025V / Vcc−0.880V |
Ka liʻiliʻi / kiʻekiʻe |
|
Haʻahaʻa ka pae uila puka |
Vcc−1.810V / Vcc−1.620V |
Ka liʻiliʻi / kiʻekiʻe |
|
Ke ala a me ka hāʻule |
1.5ns |
@ 20~80~20%Vcc |
|
Symmetry |
45~55% |
@ puka kea kiko |
|
Māhele Jitter RMS |
<1ps |
Hoʻohui ʻia 12kHz ʻoi aʻe ma mua a i ʻole like me nā fijs ʻoi aku ma mua a i ʻole like me 20MHz |
|
Nānā:Hoʻokomo ʻia ka paʻa i nā ʻokoʻa alapine ma +25 degere , ma luna o ka pae wela, ma muli o ka hoʻololi ʻana i ka uila, nā hoʻololi haʻahaʻa puka, ka haʻalulu a me ka haʻalulu. |
||
Nā hiʻohiʻona huahana
■ Nā liʻiliʻi liʻiliʻi 3.2x2.5x1.3 me 6 solder pads
■ Kiekie hilinaʻi humuhumu pūʻolo keramika
■ Launa alapine ākea
Nā noi
- Hoʻohana nui ʻia ka LVPECL Crystal Oscillator 3225-CO32P6 ma: Ke kamaʻilio wikiwiki kiʻekiʻe, nā mea paʻa lima, nā lako Telecom.
Nā mea maikaʻi o ka huahana
kiʻekiʻe kiʻekiʻe -wikiwiki a haʻahaʻa haʻahaʻa
Hāʻawi ka moʻo CO32P6 i ka hoʻopuka ʻokoʻa LVPECL a me ka -uila haʻahaʻa haʻahaʻa, e hōʻoia ana i ka pono o ka hōʻailona ʻoi aku ka maikaʻi ke hoʻohālikelike ʻia me nā oscillator hoʻopau hoʻokahi i nā loulou ʻikepili serial ma luna o ka pae gigabit.
Hoʻohui ʻokoʻa ʻokoʻa puka
ʻAʻole pono i nā mea hoʻopaʻa uʻi waho a i ʻole nā pahu hōʻailona hōʻailona.
palapala hōʻoia
ʻO ka moʻo LVPECL Crystal Oscillator 3225 CO32P6 he RoHS/REACH-hōʻoia, alakaʻi-free, a halogen-noa.
FAQ
P1: Pehea e ho'āʻo ai i kēia Thermistor{1}} LVPECL Oscillator?
A: 1) E hōʻoia i ka pololei a me ka paʻa (± ppm) ma luna o ka pae wela.
2) E ana i ka ʻokoʻa o ka hawewe puka puka (amplitude, piʻi / hāʻule manawa) ma lalo o ka ukana.
3) E hōʻoia i ka hana ʻekolu-state; inā ʻaʻohe puka, e nānā iā Enable pin bias a me ka walaʻau mana.
Nīnau 2: Nā pilikia maʻamau a me nā hopena no kēia Oscillator
A: Nīnau 1: ʻOi aku ka nui o ka Phase Jitter a i ʻole ka hawewe puka maʻemaʻe
Ke kumu: ʻO ka hoʻopau ʻokoʻa kūpono ʻole, ka walaʻau nui o ka mana, a i ʻole ka hoʻonohonoho PCB maikaʻi ʻole.
Hoʻoponopono: E hōʻoia i ka hoʻopau ʻana o 50Ω like me Vcc-2V i kau ʻia ma kahi kokoke i ka mea hoʻokipa. E hoʻomaikaʻi i ka wehe ʻana i ka mana me nā capacitors haʻahaʻa-ESL. E hoʻokaʻawale i nā hui like ʻole me ka impedance i hoʻomalu ʻia.
Puka 2: ʻAʻole pololei a i ʻole ʻaʻe ʻē aʻe ma mua o nā kikoʻī
Ke kumu: ʻAʻole hāʻule ka pōʻai pānaʻi kūloko, ʻeleʻele aniani ʻino, a i ʻole ka hana ʻana ma waho o nā kūlana ukana i ʻōlelo ʻia.
Hoʻoponopono: Hoʻololi i ka ʻāpana. E hōʻoia i ka volta komo a me ka ukana i loko o nā helu kiʻekiʻe loa a me nā kūlana hana i ʻōlelo ʻia.
